- Main Information:
-
Port Size NPT 3/4", G 3/4" Operation Pilot Operated Type 5/2 Pneumatic Control Body Material Aluminum Seals Material FKM Operating Pressure Differential 21.8 to 174 psi (1.5 to 12 bar) Media Temperature 5°F to 149°F (-15°C to 65°C) Orifice Size 0.89 Inch/22.5 (mm) Port Size 3/4” Flow Coefficient 6.5Cv (7.5Kv m3/h) Port Size 3/4” Voltage 24VDC, 110VDC, 24VAC, 220VAC Coil Fly Coil
DIN ConnectorMedia Air Filtered, Lubricated or Dry
- Features and Benefits
- Single solenoid construction for 3/2 typeDual solenoid construction for 5/2 typePoppet sealing designManual operators available
- Applicationts:
-
Actuation ControlPneumatic SystemAutomation Control
For Any Speical Requirement, please consult PRIMOFLO.
